CO2 Cylinder Filling Station

CO2 Cylinder Filling Station
CO2 Cylinder Filling Station
CO2 Cylinder Filling Station
CO2 Cylinder Filling Station

Product Details:

Title	Detail
Gas Type	Carbon Di-Oxide
Gas Container Type	Cylinder
Capacity	5 to 50 Kg Cylinder Capacity
Maximum Filling Pressure (Bar)	60 to 100 Bar(g)
Power Supply	415 / 380 Volt AC/ 3 Ph/50-60 Hz
Application/Usage	Industrial
Power Consumption	5.5 Kw for 500 Kg/hr. Cylinder Filling System
Machine Type	Semi-Automatic

Cylinder Filling Station:

SUPER CRYO, offer the Semi-automatic operated CO2 Filling Cylinder Station consisting of

Cryogenic Cylinder Filling Pump with Motor Skid.
Cylinder Filling Manifold equipped with Insulation, Safety Fittings, Pneumatically Actuated valve, Isolation valves, Instrument etc.
2 Nos. of Weighing Machine.
Flexible Hoses with one side CO2 cylinder fitting and other side Isolation valve fitting- 3 Set.
Interconnecting Piping & Fittings.
Insulation.
Electric Control Panel.
Manifold Mounting Stand.

Only the following work shall be done manually during CO2 Cylinder Filling operation

Loading of CO2 Empty cylinders to the platform of Weighing Machine
And unloading of filled Cylinders from platform of Weighing Machine

Additional Information:

Pay Mode Terms: L/C (Letter of Credit),T/T (Bank Transfer)
Port of Dispatch: BY SEA or BY ROAD
Delivery Time: Within 10-12 Weeks from the date of your confirmed order along with requisite advance Payment.
Packaging Details: Sea Worthy Packing for Export Project / Normal Packing for Indian Project
